· Ideal HT Pipe for chemical application. Ultimate chemical and corrosion resistance with particularly formulated C-PVC (Chlorinated PVC) material.

· Specialized 2 types of HT Pipe are available according to chemicals.

· Type P-10 : For sodium hydroxide
· Type T-17 : For Acid and Low salinity chlorine water

[Test for type P-10]
ESCR test in KOH
P-10 has an excellent sodium hydroxide-resistance.
Pipe under lower stress condition performs better durabillity.

Test method : Time at failure with constant load in KOH 14% by Launder Stress Cracking Tester.

Erosion test in soda electrolysis plant.
The bleached wall thickness by soda is small and mechanical properties are almost same as before the erosion test.

		Sample1	Sample2	Refarence
Terms of Use	Size	40A	50A
	Chemical	NaOH 35%	NaOH 35%
	Temperature	85℃	85℃
	Pressure	Non Pressure	Non Pressure
	Period	1Year	1Year
Tensile Strength(Mpa)		45	48	45～50
Elongation at break point(%)		98	117	80～130
Whitening depth(mm)		0.1	0.1	-
Sample photograph				-
